Match Your Application Perfectly with Siemens Modular System

Processing, fitting, transporting. These and similar functions run on many automated production lines. With the extensive range of the SIRIUS modular system, you will find everything you need for switching, protecting, starting, and monitoring motors.

The components of the SIRIUS modular system offer maximum wiring flexibility. They can be connected easily via the corresponding SIRIUS 3RV29 infeed system or the 3RA68 infeed system in conjunction with the compact starter. Both systems are respectively available for other devices with screw-type and spring-loaded connection system.

For connection, individual circuit breakers, complete load feeders, or compact starters are simply clicked into the respective infeed system. Doing away with laborious wiring and fault risks, a complete feeder group is thus supplied with power.

Design highlights include:

  • Outstanding flexibility for assembly and expansions
  • Reduced space requirements in the control cabinet thanks to compact design
  • Infeed optionally from the left or right with conductor cross-sections of up to 70 mm2
  • Optional wiring duct between the feeders
  • Additional integration of further 1-, 2-, or 3-pole components via terminal block
  • Maximum current carrying capacity of 100 A
  • Integration of load feeders with screw-type and spring-loaded connection system
  • High vibration resistance, particularly with switching devices featuring the spring-loaded connection system
  • Time savings in terms of mounting thanks to easy plug-in connection system

To learn more, download the full brochure HERE,

SIRIUS 3RW5 Soft Starter – The Next Generation

Contributing author: Jason Miller, Business Developer, Siemens Industry, Inc.

Electric motors are significant in most industries; without them, your applications wouldn’t work. Motor pump liquids, transport heavy materials, move air masses, and support the processing of raw materials. Since motors are the leading unit in your facility, they should be durable and reliable with no chances of failure. SIRIUS soft starters do just this. They limit the starting current and torque to best fit your application.

The 3RW5 family of soft starters extends Siemens product range with market leading technology features for practically every user application. The 3RW5 family is a game changer allowing Siemens to broaden their market leadership in motor control applications.

Top benefits of the 3RW52 soft starter include:

  • Compact size (less than 8” deep up to 400HP)
  • Flexible HMI choices (install the high feature, standard, or omit the display)
  • Five available communication protocols (PB, PN, MB-TCP, EIP, MB-RTU)
  • Three phases controlled for application flexibility
  • Wide range of control voltages (24V AC/DC and 110-250V AC)
  • Selectable analog or thermistor input for optimal protection of motor and load

Multiple applications of the SIRIUS 3RW5 soft starter:

  • Pump cleaning and pump stopping mode
  • Electrical ruggedness
  • Condition monitoring
  • Automatic parameterization
  • Integrated braking functions

The digital transformation of industry is in full swing and Siemens’ latest generation of soft starters supports companies in fully embracing the potential of digitization. This is particularly beneficial when it comes to economic efficiency, making it faster and easier to achieve optimum results, with permanently high availability thanks to shorter downtimes.

DOWNLOAD THE BROCHURE

Simplify Drive Installation with SINAMIC Wall Mount Kits from Siemens

Contributing author: Rudy Hauser of Siemens Industry, Inc.

The new SINAMIC wall mount kits from Siemens allow simple, direct mounting of G120C compact and G120 PM240-2 modular drives. Designed for use with the latest SINAMICS drives, these low-cost kits are easy to install and conform to NEMA 1 and UL Type 1 standards.

Available in power ranges from ½ to 200 hp, and for voltages from 230V to 690V, the streamlined, compact design is consistent for all frame sizes and provides for simple interior mounting.

SinamicsG1201

Some highlights of the SINAMICS wall mount kits include:

  • Conforms to NEMA 1/UL Type 1 standards for interior installations
  • Accommodates all G120C/PM240-2/PM240P-2 power modules, control units and operator panels
  • Standardized design for optimum space utilization and for efficient side-by-side mounting with minimal clearances
  • Multiple conduit knockout holes provided for separate power, motor, and network cabling
  • Designed in accordance with the latest applicable UL 61800-5-1 standards for AC drives

Each wall mount kit provides best-in-class space savings and direct access to drive-mounted operator panels for simple commissioning, monitoring, and troubleshooting.

Click HERE to visit Siemens’ website for specific product information or download the brochure below.

SIMATIC Field PG M5

The SIMATIC Field PG M5 is now available with Siemens TIA Portal V15 engineering framework pre-installed. It is ideal for mobile operations in industrial facilities.

 field-pg-m5-sideview-700

Features Include:

  • Easy to configure, install and service
  • Rugged and lightweight design for mobility
  • Variety of interfaces available
  • Ready to go for immediate use

To learn more about the SIMATIC Field PG M5 CLICK HERE.

SIMOCODE pro: Multifunctional, Safe, and Reliable

IMOCODE pro from Siemens is a flexible, modular motor management system for low-voltage motors with constant speeds. Its preferred use is for the protection and control of pumps, gate valves, or valves.

Two series of devices allow flexible use depending on plant requirements: SIMOCODE pro S is the smart, compact entry-level solution for motor management in standard applications. It meets the most important requirements, e.g. for overload and thermistor motor protection, as well as ground-fault monitoring. SIMOCODE pro V, on the other hand, offers additional variable and intelligent functions such as voltage and frequency measurement or even fail-safe shutdown.

SimocodePro_andV

Highlights of the SIMOCODE pro include:

  • Multifunctional, electronic full motor protection, independent of the automation system
  • Communication via PROFIBUS, PROFINET, PC, UA, Modbus, and EtherNet/IP
  • Detailed operational, service, and diagnostics data for flexible use
  • Versatile integration of process sensors such as temperature of fill level measurement
  • Easy installation and maintenance
  • Easy integration and diagnosis in the SIMATIC process control system by means of function blocks
  • Efficient, intuitive engineering thanks to integration of SIMOCODE ES into the TIA portal

The range of functions extends from simple current, voltage, and power measurement to the detection of rotational direction, or drive belt slippage or breakage, to the monitoring of pumps for dry running, filter clogging, and flow or fill levels – all in one system. With SIMOCODE pro, you benefit from extremely easy user guidance and high-level process quality, while keeping costs for planning, installation, operation, and maintenance to a minimum.

Click HERE for more information on SIMOCODE pro by Siemens.

SIMATIC Controller Central Processing Unit

Sophisticated Applications Addressed…

Siemens new Central Processing Unit additions to the SIMATIC S7-1500 family are suitable for applications with medium/high requirements with regards to processing speeds and size of the program.

CPUS7-1516TF-3PNDP                                      CPUS7-1516T-3PNDP
CPUS7-1516TF-3PNDP                                            CPUS7-1516T-3PNDP

Key features of the 1516T-3 PN/DP model include::

  • Technology Integration Functions
  • Advanced Motion Control Functions
  • Integrated Security and System Diagnostics
  • Suitable for distributed configuration via PROFINET IO and PROFIBUS DP
  • Fail-safe option, the CPU S7-1516TF-3 PN/DP

To read more CLICK HERE.

SINAMICS S210 Servo Drive System

Rugged, Flexible, and Safe

The flexible and versatile SINAMICS S210 system is a single access AC/AC servo converter system, its high performance, and dynamic response is ideal for mid-range motion control applications.
M_S210_frontal_style_sRGB

The SINAMICS S210 is ideal for the following applications:



  • Packaging machines
  • Handling equipment
  • Feed and withdrawal devices
  • Stacking units
  • Automatic assembly machines
  • Laboratory automation
  • Woodworking, glass and ceramic industries
  • Digital printing machines

To learn more about the SINAMICS S210 system, CLICK HERE.

TIA Portal V14

Siemens has recently released a new version of the Totally Integrated Automation Portal.  New release includes a large variety of new functions for different parts of the Portal: Step 7, Step 7 Safety, WinCC, SINAMCS StartDrive, SIMOTION Scout.
TIA Portal V14 offers multiple new features including:
– Multiuser Engineering
– Teamcenter Gateway
– Cloud Connector and more…

The chart below shows overview of the all new options in V14:
TIA Portal_072517

Existing users can take advantage of multiple ways to upgrade their software to V14, like:
– SUS (Software Update Service) which has been extended to Nov/19/2016;
– One time software upgrade from one of the previous versions to the most current on;.
– Power packs which allow user to upgrade the functionality from version Basic to Professional.

For new users Siemens offers download of the 21-days trial version of the software.

To obtain more information or order the software please contact us at http://www.seawi.com/contact-us/.

Sinamics V20 – Cost Effective, Easy to Use

Sinamics-Web-Page-Header

The Sinamics V20 is the cost effective and versatile inverter for basic demands.

Today, in an increasing number of applications in plant and machinery construction, individual automation and drive solutions are demanded that automate simple motion sequences with low associated requirements. With its compact SINAMICS V20, the basic performance inverter, Siemens offers a simple and cost-effective drive solution for these types of applications. SINAMICS V20 sets itself apart with its quick commissioning times, ease of operation, robustness and cost-efficiency. With four frame sizes, it covers a power range extending from 0.12 kW up to 15 kW (1/6 hp up to 20 hp).



Minimize your costs

Engineering, commissioning and operating costs as well as those in operation must be kept as low as possible. You have precisely the right answer with our SINAMICS V20. To increase energy efficiency, the inverter is equipped with a control technique to achieve optimum energy efficiency through automatic flux reduction. Not only this, it displays the actual energy consumption and has additional, integ rated energy-saving functions. This allows energy consumption to be slashed drastically.



Key Features



– Motor speed can be regulated, which allows a reduction of energy costs in basic applications
– Equipped with power optimized control method (ECO Mode) which adapts the magnetic blocks within the motor to the corresponding operating point
– Frost and condensation protection prevents moisture in motors under extreme environmental conditions
– Higher productivity with uninterrupted production due to Keep Running Mode
– Exchange of regenerative energy via the DC link
– Direct control of mechanical holding brake
– Broken belt detection by monitoring the load torque
– High availability through automatic restart and flying restart after power failures





Click here to browse the Sinamics V20 Family







Need to Quickly Implement an Application at a Favorable Price?



Sinamics-Web-Page-Header



Easy to install
• Push-through and wall mounting –
side-by-side possible for both
• USS and Modbus RTU at terminals
• Integrated braking chopper for 7.5 kW to 15 kW
(10 hp up to 20 hp)

Easy to use
• Parameter loading without power supply
• Integrated application and connection macros
• Keep Running Mode for uninterrupted operation
• Wide voltage range, advanced cooling design and
coated PCBs increase robustness

Easy to save money
• ECO mode for V/f, V2/f
• Hibernation mode
• DC coupling





TYPICAL APPLICATIONS

Typical Applications





 Browse Sinamics V20 Products





For more information on Sinamics V20 Basic Inverters, please contact your Standard Electric Account Manager

Sinamics V20 Drives for Basic Applications

Sinamics-Web-Page-Header

Siemens now offers a simple and cost-effective drive solution with its compact SINAMICS V20 Basic Performance inverter.



The SINAMICS V20 sets itself apart as a result of its quick commissioning times, ease of operation, robustness and cost-efficiency. With four frame sizes, it covers a power range extending from 0.12 kW up to 15 kW.

MINIMIZE YOUR COSTS

Engineering, commissioning and operating costs as well as those in operation must be kept as low as possible. You have precisely the right answer with our SINAMICS V20. To increase energy efficiency, the inverter is equipped with a control technique to achieve optimum energy efficiency through automatic flux reduction. Not only this, it displays the actual energy consumption and has additional, integ rated energy-saving functions. This allows energy consumption to be slashed drastically.

 Sinamics Cost Savings Screenshot

For more information on stock and pricing, please contact your Standard Electric Account Manager
